TORNO 16'' X 60'' PARTE: 2GM-GML-1660HD
16” x 60”, 2-1/16” bore, 6 HP
- ISO 9001 certified
- Large spindle bore 2-1/16”
- Heavy Duty spindle D1-6
- One-piece solid cast iron machine base
- Heavy Duty guideway width 10-1/4”
- Heavy Duty main motor 6 HP
- 16 spindle speeds from 45-1,800 rpm, speeds: 45/70/90/108/140/165/215/255/330/385/510/585/770/900/1170/1800rpm
- 45 kinds of inch threads, and 39 kinds of metric threads
- Threading and feeding rate change without changing gears
- Spindle is balanced, hardened and precision ground
- Spindle is supported at 3-point by high precision bearings
- All gears and shafts are hardened and precision ground
- Guideways induction hardened and precision ground
- Automatic lubrication system in headstock and feed box
- SINO DRO (installed)
- Taper turning attachment (installed)
- 8” 3-jaw chuck with one set of reversible jaws
- 10” 4-jaw chuck
- 12” Face plate
- 5 1/2” large steady rest with roller jaws (bearings)
- Oil pump on Apron for all guideways and leadscrews
- 2” follow rest with roller jaws (bearings)
- Removeable gap
- 4-way tools post
- Foot brake
- Halogen Work light and coolant system
- Full length splash guard
- (2) dead centers and (1) reducing sleeve MT6/MT4
- Thread chasing dial
- Tool box and leveling pads
| Max. swing over bed | 16 1/16" |
| Max. length of workpiece | 60" |
| Max. swing over cross slide | 10 1/4" |
| Max. Swing in gap | 23 1/4" |
| Width of Bed | 10 1/4" |
| Effective length in gap to spindle | 8 1/2" |
| Effective length in gap to chuck jaws | 3 1/2" |
| Spindle bore | 2 1/16" D1-6 |
| Taper of spindle center | M.T. #6 (MT6/MT4 sleeve) |
| Spindle speeds | 45-1,800 rpm / 16 steps |
| Longitudinal feeds | 0.0018-0.07 IPR, 42 kinds |
| Cross feeds | 0.0009-0.03 IPR, 42 kinds |
| Inch threads | 70-2 TPI, 45 kinds |
| Metric threads | 0.2-14 mm , 39 kinds |
| Diametral Pitch threads | 8-40 DP , 21 kinds |
| Module threads | 0.3-3.6 mm, 18 kinds |
| Max. travel of top slide | 4 1/4" |
| Max. travel of cross slide | 8 1/2" |
Spindle length w/o chuck Leadscrew length X TPI | 20 1/2" 1 1/4" x 4 TPI |
| Diameter of tailstock quill | 2 1/16" |
Max. travel of tailstock quill | 5" |
| Taper of tailstock quill center | MT4 |
| Main motor | 6 HP, 220V/20A, 3 Phase |
| Coolant pump | 1/8 HP, 220V, 3 Phase |
