PARTE # 2TA-BR-52 – TALADRO MULTIPLE HORIZONTAL DE 1 LADO – 50” LARGO
New with warranty
Suitable and affordable for industrial and small workshop use.
Capable of using "multiple drill head" for the drill distance less then 2".
Easily adjust the drill position and add more drill spindles.
Pneumatic clamp and drill head travel operated by foot pedal, hands free.
Pneumatic and hydraulically stroke control for max. drilling power.
Each spindle can be horizontally adjusted in position quickly.
Cast iron base and table for durable usage.
OPTIONAL Multiple Drills Head.
BR- 52SD - EXTRA DRILL CHUCK SPINDLE
BR- 52MDC - EXTRA SPINDLE FOR GEAR DRILL HEAD
BR-101 - BASIC SINGLE DRILL UNIT
BR-103 - BASIC SINGLE UNIVERSAL DRILL UNIT
SPECIFICATIONS | BR-52 | BR-54 | BR-2072 | BR-4080B |
Motor (3 PH) | 3 HP x 2 | 3HP x 2 | 3 HP x 2 | 3 HP x 2 |
(PREWIRE) | 110/230V | 110/230V | 110/230V | 110/230V |
Drill Speed (RPM) | 3400 | 3400 | 3400 | 3400 |
Drill Chuck | 1/2" | 1/2" | 1/2" | 1/2' |
Spindle Stroke (Max.) | 4" | 4" | 4" | 4" |
Table Size(W x L) | 18" x 50" | 18" x 72" | 10" x 72" | 18" x 49" |
Max. working Length | 50" | 72" | 72" | 48" |
Multiple Drill Head Available | Yes | Yes | Yes | No |
Air Clamp | 2.5 | 5.5 | 5.5 | 11 |
Standard Drill Spindle | 4 |
|
|
|
Max. Drill Spindle |
|
|
|
|
Max. Drill Distance (Chuck Type) | 2" | 2" | 2" | 2" |
N.W. | 2710 LBS | 3180 LBS | 4200 LBS | 3960 LBS |
G.W. | 2980 LBS | 3420 LBS | 4800 LBS | 4380 LBS |
Pago y Devoluciones
- Forma de pago
- Visa/Mastercard/American Express
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
PART: 1AM-3010-E – ROLLER STAND - INFEED - OUTFEED - 120 CM (47”) LENGTH
PART:
1AM-3010-E – ROLLER STAND - INFEED - OUTFEED - 120 CM (47”) LENGTH
SIDE
ROLLER TABLES Use
with saws, planers, edgebanders, jointers, etc.120
cm (47”) length x 39 cm (15.35”) widthVariable
height 83 - 87 cm (32.5 - 34.25”)Support
large and heavy wood pieces and wood panelsAdjustable
heigh to pair with your current machines
7
galvanized steel ball bearing rollersOptional:
- Custom lengths
AMXmachinery
SIERRA CINTA 24"
PARTE # SIL-DC-BS0024 - SIERRA CINTA DE 24" - MOTOR 4 HPNUEVA CON GARANTIAMOTOR: 4 HP, 220V, 60 Hz, 1 FASECAPACIDAD DE CORTE: 23" X 11"LONGITUD DE LA SIERRA: 4080 MMANCHO DE LA SIERRA CINTA: DESDE 3/8" HASTA 1-1/2"VELOCIDAD DE LA CINTA: 10 MTS/SEGTAMANO DE LA MESA: 23" X 19"ALTURA DE LA MESA: 37"INCLINACION DE LA MESA: 10 - 45 GRADOSPESO: 330 KGSEMPAQUE: 1 CAJA
AMXmachinery
PARTE: 12484 - TORNO OKUMA - CNC LB-15
PARTE: 12484 - TORNO OKUMA
- CNC LB-15
USADO BUENAS CONDICIONES
AMXmachinery
PARTE: 2BA-PICO – ESPIGADORA MESA DOBLE - BALESTRINI PICO
PARTE: 2BA-PICO – ESPIGADORA MESA DOBLE - BALESTRINI PICOThe PICO machine cuts round dowels or round end tenons on chair and case goods components. PICO cuts horizontal or vertical tenons on three compound angles sim-ultaneously without the use of special fixtures. The PICO machine is equipped with the exclusive, patented Balestrini anti-splitting cycle. With this system, the tables are fixed and the tool always enters the wood with the grain (climb cutting) and eliminates any tear-out.The PIC...
