Identificador: 297
Abierta
Descripción
PARTE: 2TA-R-1318 – ROUTER CNC – MESA 13”X 18”
3 Axis table top machine easily to do cutting, engraving, routing and etching for signs, sample or small production at the material such as wood, plastic, acrylic, plexi-glass, corian....
User friendly iPicture software transfers the images, picture file to 3D cutting program with in a second at superior performance.
Optional CAD/CAM system can create and edit part programs then send to machine for cutting. DXF files can be imported, modified and edited from here to create a G code too.
Moving gantry construction for space saving.
Linear guides and sliding blocks are prismatic pre-loaded with recirculation bearings to ensure maximum rapid traverse and precision.
All the axis are equipped with a bolt screw driving system
MODEL NO. | R-1318 | R-1520 |
X AXIS MAX. WORK SIZE | 13” | 15.3” |
Y AXIS MAX. WORK SIZE | 18 | 20.5” |
Z AXIS MAX. WORK SIZE | 3” | 4.13” |
POSITION ACCURACY | 0.004” | 0.003” |
SPINDLE POWER (DC Brushless) | 150 W | 500 W |
SPINDLE (RPM) | 15000 | 23000 |
TOOL COLLET | 1 / 4” | 1 / 4” |
AXIS DRIVING MOTOR | STEP | STEP |
PC SOFTWARE | iPicture | iPicture |
INTERFACE | USB Port | USB Port |
CAD/CAM SOFTWARE | Optional | Optional |
MACHINE SIZE | 25” x 22” x 21” | 33” x 43” x 27” |
WEIGHT (LBS) | 122 | 132 |
Pago y Devoluciones
- Forma de pago
- N/A
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
PARTE: 12614 - REASERRADORA HORIZONTAL - 1 BANDA – 12” ANCHO X 12” ALTO
PARTE: 12614 - REASERRADORA HORIZONTAL - 1 BANDA – 12” ANCHO X 12” ALTOUsada - Buenas condicionesBAKERBBR-0 / ABXFeatures the frame and headrig of our "BX" model, but use an "AX" model conveyor belt. This means that the head-rig can be adjusted up or down and the conveyor stays at a fixed height.Because the conveyor belt stays at a fixed height, it is easier to interchange and integrate with other material handling systems in your facility. This versatile band resaw is perfect for those wh...
AMXmachinery
MAQUINA BALANCEADORA - EQUILIBRADO - MOTORES
PARTE:
3JP-PHQ-500H - MAQUINA BALANCEADORA - EQUILIBRADO - MOTORESMAQUINA BALANCEADORA DE EQUILIBRADO DE TRANSMISION POR CORREACon sistema de medición por computadoraNueva con garantía• Uso de la máquina El cuerpo de la
máquina de hierro fundido puede utilizarse durante muchos años.• Combinado con un sistema de control de
computadora industrial de 17 pulgadas y pantalla LCD.• Impresora láser combinada gratuita, para
que pueda imprimir el informe de pruebas de balanceo.• La má...
AMXmachinery
PARTE: 2AM-U-500 - ARMADORA DE MARCOS PROGRAMABLE - 1 CANAL
PARTE: 2AM-U-500 - ARMADORA DE MARCOS PROGRAMABLE - 1 CANALOur U-500 is recommended for high-volume production facilities that require the primary use of a single sized V-Nail for frame joining. The U-500 has the same user-friendly, touch screen interface as our U-600 Underpinner. The only difference between the two models being the U-500 has single channel capacity compared to a multi-channel with the U-600 unit.With data storage of 5,000 different frame profiles, the operator can easily recall...
AMXmachinery
PARTE: AMX-12490 - EXTRACTOR DE TURBINA - DAYTON
PARTE: AMX-12490 - EXTRACTOR DE TURBINA - DAYTONUSADO - MUY BUENAS CONDICIONESBALEROS NUEVOSMedidas totales: 25” ancho x 17”
fondo x 20” altoEntrada redonda: 7”Salida redonda: 5”
Motor: 3 HP, 230/460V, Amp 8.2/4.1,
RPM 3490, Marca Dayton Video: https://vimeo.com/870516485
