REASERRADORA HORIZONTAL – 1 SIERRA BANDA – 300 MM ANCHO X 250 MM ALTO
AMXmachinery
Descripción
PARTE: 3HP-HP-11P - REASERRADORA HORIZONTAL – 1 SIERRA BANDA – 300 MM ANCHO X 250 MM ALTO
Con sistema de control hidráulico
Nueva con garantía
Specifications:
1.With digital readout
2.Max. workpiece size: 300mm(W) x 250mm(H)
3.Distance from blade to conveyor Table: 3-125mm
4.Conveyor belt size: 285mm x 5470mm
5.Saw wheel dimension: Φ28" x 1"(Thickness)
6.Max. infeed speed: 16M/min OPTIONAL: 25M/min.
7.Saw blade size: 168" x 1"
8.Saw wheel motor: 20HP
9.Controlling blade tension: Hydraulic system
10.Hydraulic system: Motor 3HP / Infeed conveyor table by hyd. motor
11.Gear box motor: 1/4HP
12.Dust hood diameter: ψ4" x4
13.Net weight: 1108kgs
14.Packing dimensions with pallet:
- Frame : 2170 x 1100 x 1120mm / 901 KG
- Conveyor: 2870 x 620 x 750mm / 207 KG
15.Min. working length request: 400mm (shorter length upon request)
16.Pneumatic pressure roller system for accurate cutting
17.Front pressure roller with air cylinder and shock absorber
18.Tolorance: ±0.1ｍｍ
19.Mist coolant system & saw dust scraper
20._______Volt, _______Hertz
