ID: 96
Open
Description
PARTE # 2EV-6000 - POSTFORMADORA CONTINUA 1 LADO - EVANS 6000
220 Volt 1 phase, 220 volt 3 phase
Standard Features:
Floating Laminate Trimmer (conventional router)
Three phase machines require a separate 110 connection
Quick-change 90 and 180 degree roller assembles.
Infrared radiant panel heater (instant on / off)
Foot print: 130”L X 36”W X 50”H
Maximum Feed rate 15 feet per minute.
Feed motor: 1/3 hp variable speed DC drive.
Crated dimensions 125 x 40 x 60
Created weight 1750 LBS.
Option:
High Frequency trimmer (single or three phase)
Extra Cassette
Video de la maquina trabajando: VIDEO 1
Payments & Returns
- Payment Methods
- Visa/Mastercard/American Express
Post Message
Sign in to ask the seller a question.
AMXmachinery
ASERRADERO
PARTE: 1CL-0550 - ASERRADERO ESTACIONARIO - 40" DIAMETRONuevo con garantiaAltura maxima de corte 100 CMSVolante de 40" diametro y ancho de 4" para cinta de 5" de anchoMotor de 20 HPProcesa aproximadamente 7,000 pies tabla por turnoAltura total 125"Largo de la cinta: 6.58 mtsPeso 750 kgsOPCIONALES- PARTE: 1CL-0501 - CARRO 2 ESCUADRAS PARA ASERRIO DE TROZO HASTA 10 PIES DE LARGO- PARTE: 1CL-0502 - CARRO 3 ESCUADRAS PARA ASERRIO DE TROZO HASTA 20 PIES DE LARGOVideo maquina funcionando: VIDEO 1
AMXmachinery
SIERRA VERTICAL ELCON ESPECIAL 1
ELCON 320 DSX-E TO CUT THROUGHT 0-135 MM AUMINUMA vertical panel saw can be used to cut through various materials, like wood based,plastics, composites etc.This episode's custom built Elcon panel saw was developed to cut through aluminium tailgate / cargolift. A bar code scanner tells the machine to cut off the left and left and right side. The sawing speed is automatically adjusted to the thickness of the material, in this case up to 135mm!
AMXmachinery
PARTE: 12533 - ESCOPLO OSCILANTE - 2 MESAS - BALESTRINI
PARTE: 12533 - ESCOPLO OSCILANTE -
2 MESAS - BALESTRINI
USADO - MUY BUENAS CONDICIONESModelo MicronMax
oscillation length: 120mm (4.8")Max
slot depth: 80mm (3.2")Max
slot thickness: 30mm (1.2")Hourly
production: 500-800 slotsSpindle
rotation: 9,000 RPMOscillations
per min.: 60-350Max
table inclination: 20 degreesTables
19" x 9"Pneumatic
holddown on each tableSpindle
motor: 3HPOscillation
motor: 1/2HP
Current
Voltage: 220v
AMXmachinery
PARTE: 2NV-KDK-42DS - SECANTE DE MADERA - CAPACIDAD 35,000 PIES TABLA
PARTE: 2NV-KDK-42DS - SECANTE DE MADERA - CAPACIDAD 35,000 PIES TABLAUna estufa propia puede reducir los costos de almacenamiento, producción, transporte y dar valor agregado a su producción.Contactenos para una cotizacion detallada.
