Identificador: 25
Abierta
Descripción
PARTE: 2TA-TG-6000 – AFILADORA DE CUCHILLAS RECTAS
Nueva con garantia
Features:
Heavy-duty straight knife grinder, rapid for grinding processing and saving time.
Economical model and efficiency for processing high powerful of any straight knife grinding such as Planner & Jointer Knife, Peeling Knife, Super Surface Knife, and Veneer Cutting Knife.
Automatic grinding table movement forward and backward, label saver.
Employed with straight linear motion guides bearing to ensure longitudinal feed traverse smoothly and accurately.
The knife can be put through a coarse wheel grinding, then a fine wheel grinding for sharpening the knife edge again to obtain the super sharp edge and extend the cutting life of the knife.
Built in coolant pump for faster grinding.
Heavy sheet metal cabinet stand and cast iron body.
High precision and durability.
SPECIFICATIONS | 2TA-TG-3000 | 2TA-TG-5000 | 2TA-TG-6000 |
Grinding Capacity |
|
|
|
Cutter (Dia. x W) | 9" x 8" | N/A | N/A |
Carbide Saw (Dia. x T) | 20" x 3/8" | N/A | N/A |
Carbide Knife (L x W x T) | 12" x 1½" x ¼" | 25" x 3" x 5/8" | 25" x 3" x 5/8" |
Router Bits (Shank) Max. | ½" | N/A | N/A |
Grinding Wheel Size | 6" x 5/8" | 4" x 2" x 5/8" | 10" x 2/3" x 1" |
Grinding Head Travel | 14" | 26" | 26" |
Grinding Wheel Speed | 5000RPM | 1700 RPM | 1700 RPM |
Fine Grinding Wheel Size | N/A | --- | 4" x 2" x 2" |
Grinding Wheel Motor | 1 HP | ½ HP | 1 HP |
Fine Wheel Motor | N/A | --- | --- |
Table Size | 28' L x 8" W | 26" L | 27" L |
Table Travel | 20" x 7" | (Wheel) | 28" |
Table Travel Motor | --- | ¼ HP | ¼ HP |
Coolant Pump Motor | 1/8 HP | N/A | 1/8 HP |
N.W. (LBS) | 748 LBS | 340 LBS | 660 LBS |
G. W. (LBS) | 924 LBS | 430 LBS | 836 LBS |
Pago y Devoluciones
- Forma de pago
- Transferencia/Deposito Bancario
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
PISTOLA SAND BLASTER
PARTE: 1SIL-DC-A3071 - PISTOLA PARA SAND BLASTER ARENADO8 piezas incluidasManguera 10 piesPara presion 60-90 PSI
AMXmachinery
PRENSA PARA PANELES CURVOS
PARTE: 2TY-80-2407 - PRENSA
PARA PANELES CURVOS
NUEVA CON GARANTIA
EJEMPLO ATAUDES
AMXmachinery
PARTE: 11787 – LIJADORA DE CEPILLOS Y DISCOS - TIMESAVERS
PARTE: 11787 – LIJADORA DE CEPILLOS Y DISCOS - TIMESAVERSEn buenas condicionesModelo: 337-6RPRotary polisher has six (6) 1/2HP counter-rotating arbors with fladder-style abrasives.Rotation 12-35 RPM, 2HP variable feed 15-45 FPM on conveyor belt with vacuum bed. (Less vacuum pump unit).36” width capacity. Each arbor/spindle is 12”-long x 2”-diameter, arbor speed 100-1200 RPM, with LED readout on RPM. 0” – 6” motorized part thickness opening.Infeed and outfeed pinch rolls.Wired 460V...
AMXmachinery
ESPIGADORA DOBLE DE CADENA - (2) MAQUINAS - CAP. 54” ANCHO Y 110” LARGO
PARTE: 11754 - ESPIGADORA DOBLE DE CADENA - (2)
MAQUINAS - CAP. 54” ANCHO Y 110” LARGO
4 - SIERRAS DOBLES. SIERRAS MARCA IND. G.H. PARA
ESCUADRAR MATERIAL HASTA DE 54” DE ANCHO Y 110” DE LARGO, QUIPADA CON 4 SIERRAS
DE 60 DIENTES EN 1/16 DE GROSOR ACCIONADA POR UNA BANDA, ROLES Y MICRO PARA
DIMENSIONAR Y CORTAR.
