Identificador: 282
Abierta
Descripción
PARTE: 2TA-CM-200LG - PERSIANERA PARA HACER SHUTTERS
Features:
- A faster round louver groove mortise machine provides variable oscillating speed.
- Distance between the slot is controlled by the template.
- Two working tables built in both side of the machine to double the production for high efficiency mortising operation.
- Automatic pneumatic hold down clamps
- Fully automatic mortise produce cycles.
- Pneumatic pistons for drilling depth speed control, enable for best results.
- Depth of mortising is easily adjustable.
- Powerful industrial motor for maximum cutting capacity.
- Precision sealed long life bearing.
- Heavy cast iron frames and table for durability usage.
| Specifications | CM-200LG |
|---|---|
| Slot per Minute on 2 Working Pieces | 20 holes |
| Adjustable Slot | 0°~90° |
| Max. Depth of the Slot | 1" (30 mm) |
| Max. Size of the Working Piece | 4" x 5" (100 x 130 mm) |
| Min. Size of the Working Piece | 0.39" x 1" (10 x 30 mm) |
| Bits Rotation | 12000 RPM |
| Bits motor Power | 5 HP |
| Sliding Motor | 1 HP |
| Machine Size | 158" x 45" x 47" (4000 x 1140 x 1200 mm) |
| Packing Size (Packing Mold) | 118" x 4" x 2" (3000 x 100 x 40 mm) |
Packing Size(Packing Machine) | 83" x 45" x 55" (2100 x 1145 x 1400 mm) |
| N.W. | 1962 LBS (890 kg) |
| G.W. | 2315 LBS (1050 kg) |
Pago y Devoluciones
- Forma de pago
- Transferencia/Deposito Bancario
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
ASTILLADOR - 75 HP - BAJA VELOCIDAD - WEIMA
PARTE: 12406 - ASTILLADOR - 75 HP - BAJA VELOCIDAD - WEIMA
Usado - Buenas Condiciones2004
Model WLK 13/75 Low Speed, Hopper StyleBatch
style with 75 HP low speed rotor, top feed hopper, self contained hydraulic
system with hydraulic ram, and controls.
Controls
operate the ram which forces material against the low speed rotor. Controls
vary the hydraulic pressure based upon the load on the rotor motor.
Features
reversible carbide cutters on large diameter rot...
AMXmachinery
PARTE: 1SL-DC-BV25B - TORNO PARA METAL DE 240 X 400 MM
PARTE: 1SL-DC-BV25B - TORNO PARA METAL DE 240 X 400 MMNUEVO CON GARANTIAMOTOR 1 HP, 220V, 60 Hz, 2 FASESCAPACIDAD DE VOLTEO: 240 MMDISTANCIA ENTRE PUNTOS: 400 MMDIAMETRO DEL CHUCK: 125 MMVELOCIDADES: 6 VELS (115-1620 RPM)DIAMETRO HUSILLO: 25 MMPESO: 135 KGSTIPO DE EMPAQUE: 1 CAJA ACCESORIOS PARA EL TORNO - SE VENDEN POR SEPARADO:- CHUCK DE 4 MORDAZAS - DC-4JC- CONTRAPUNTO GIRATIRIO (CONO MT2) - DC-RC- LUNETA FIJA - DC-SR- LUNERA VIAJERA - DC-FR
AMXmachinery
LIJADORA DE TAMBOR 50"
PARTE # 2SM-750102 - LIJADORA DE 2 TAMBORES - 50" DE ANCHO – 7.5 HP, 220V, 1 FASEPARTE # 2SM-750302 - LIJADORA DE 2 TAMBORES - 50" DE ANCHO – 7.5 HP, 220V, 3 FASES SPECIFICATIONSSanding Capacity:Maximum Width (in): 25, 37, 50Minimum Length (in): 3-1/2Maximum Thickness (in): 25″ model: 637″ & 50″ models: 12Minimum Thickness (in): 1/32Dimensions HxWxD (in):25″ model: 43 x 46 x 3137″ model: 43 x 58 x 3150″ model: 50 x 71 x 31Drum (in): (extruded aluminum)25″ model: 5 x 2537″ ...
AMXmachinery
ALIMENTADOR AUTOMATICO - PARA REASERRADORA - 3/4 HP
PARTE: 1N-ALI-001 – ALIMENTADOR AUTOMATICO - PARA REASERRADORA - 3/4 HPNuevo con garantía
Para Sierras Cintas y Reaserradoras Industriales
Para uso industrial, rudo y continuo
Para re-aserrar o tabletear
MOTOR 3/4 HP, 220V/440V, 3 FASES, 800 RPM DIAMETRO DE LA PINA 7-1/2""LARGO DE LA PINA 8"LARGO DEL BRAZO 28"3 VELOCODADES:VELOCIDAD 1: 6 MTS/MIN - PARA TABLAS DE 9" A 12" DE ALTO APROX.VELOCIDAD 2: 8 MTS/MIN - PARA TABLAS DE 7" A 8" DE ALTO APROX.VELOCIDAD 3: 12...
