PARTE: 2NT-8-1100RC – LIJADORA DE BANDA ANCHA – 43” ANCHO – 2 BANDAS
NUEVA CON GARANTIA
• Max Working Width: 1100mm / 43"
• Configuration: Roller-Combination Head
• Number of heads: 2
* 1st Head 8" 65 Shore Rubber Contact Drum
* 2nd Combination Head with 4" rubber contact drum with 65/70 Shore Platen
• Motor: 30HP
• Size of Sanding Belt: 43-3/4" x 75"
• Mechanical Variable Speed 16 - 47.2fpm
• Max Working Height: 150mm / 5.9"
• Feed Motor: 2HP
• Table Lifting & Lower Motor: 1/4HP
• Dust Collection: (8) 5" port: 681 CFM @ points of extraction
• Amperage requirements: 230V / 460V 60HZ, 3PH: 79A / 39.5A
• Machine / Packing weight: 3,316lbs / 3,826lbs
• Machine / Packing dimensions (LxWxH): 60" x 61" x 75" / 63" x 66" x 84"
• (1) Tool box and manual
• Warranty is one year parts
• Northtech offers a full line of dust collectors for any application.
• All machines are tested stateside prior to shipment providing trouble free start up.
FEATURES
• Centralized control center with visual load meter and digital elevation
control.
• Power supply light with emergency stop control.
• Individual start/stop controls for feed and sanding head.
• Mechanical feed adjustment allows operator to change desired
feed speed from 16-47.2fpm.
• Single 30HP TEFC motor rated for continuous use delivers constant
power to sanding surfaces.
• Triple V-belt drive for full power delivery to sanding surface.
• Disc braking for rapid emergency stops.
• Full access door with lock on outbound side.
Single head shown for reference only.
• Each sanding head has quick adjust belt tracking on inbound side.
• Strong 4-Jack elevation control for parallel, precise and repeatable
sanding quality.
• 1st Head 8" 65 Shore Rubber Contact Drum
• 1/4 Turn head lock with removable puck.
* 2nd Combination Head with 4" rubber contact drum with 65/70 Shore Platen.
• 1/4 Turn head lock with removable puck.
• Individual roller and platen adjustment.
• Upper and lower elevation protection switches prevent machine
from crashing.
• (8) 5" dust port require 681 CFM @ point of extraction.
• Dust port formed into machine body for superb fugitive dust control.
• Belt tracking cycle speed is easily adjustable for product specific
oscillation.
• All sanding heads equipped with a quick switch pneumatic belt
tensioner.
• Single pneumatic hookup with regulator, filter, and master shut off
included.
• Electronic belt tracking with automatic jet blow off cleaner.
• Belt monitoring switch shuts down machine if a belt brakes as well as
prevents head from starting if not activated.
• UL/CE certified controls and electrical components are neatly
labeled and organized in the electrical cabinet.
