Identificador: 2047
Abierta
.jpg)
.jpg)
.jpg)
Descripción
PARTE: 2TA-SET-106TS – ESPIGADORA DOBLE DE CADENA – 6 CABEZAS – 120” ANCHO
Nueva con garantia
Opcionales:
Extra Infeed 42” Length
Total Enclosure Cover
Feed Magazine
Auto Transfer Line (4 ft x 8 ft) Transfer Table
Optional Jump Shaper and Finish Shaper Cutter heads
Optional Center Split Saw Station
Features:
• The automatic high-speed through feed device allows for perfect finishing at speeds ranging
from 12 ~ 52 FPM.
• Suitable for mass production of woodworking factory for processing of double end cutting,
tenoning, grooving, moulding, and sanding.
• Scoring Saw, Trim Saw , Hogging/ Coping Shaper: Total 3 stations at each sides.
• Reversed direction cutting jump shaper head with sensor for automatic move in and out for
prefect cutting to prevent tearing at end edge.
• It is a powerful machine great for heavy-duty production.
• In addition to the double end cutting, all the settings and other processing can also be executed
with high accuracy
Since the machine is so versatile, we believe it will be one of the most satisfactory machines for
bulk production lumber-processing factories.
• The specially designed numeric controller allows quick setting of sizes for tolerance within
0.004”.
• Variable speed, through feed, wide rubber pad, spring-loaded dots conveyor for the best finish
selections.
• Heavy-duty pressure rolls at top of wide width conveyor to hold the material tight to prevent
sliding during the cutting process.
• Shaper head can be moved up & down, forward & backward.
• Equipped with industrial motor for full power cutting capacity.
SPECIFICATIONS: SET-86TS / 106TS-SJC
Max. Working Thickness 2”
Max. Working Length 96" / 120”
Trim Saw Blade (Diameter) 10" x 1"
Shaper Cutter (Diameter) 6" ~ 8" x 1"
Feed Speed 12' ~ 52' Variable
Motor 3 PH, 220/440 V
Trim Saw 10 HP x 2
Jump Shaper 7-1/2 HP x 2
Fixed Shaper 7-1/2 HP x 2
Sanding ---
Feeding 2 HP x 1
Width Setting ½ HP x 1
Machine Size (L x W x L) 13' /15' x 8' x 6'
N.W. 3500 / 3800 LBS
