ENCHAPADORA

PARTE # 2TA-EB-7B - ENCHAPADORA DE CANTOS RECTOS

 Automatic feed station for: Pre-milling, Gluing, Pneumatic Guillotine, Double End trimming, Top & Bottom Rough Edge Trimming, Corner Rounding & Fine Top & Bottom Fine Edge trimming, Edge Scraping, Grooving, Edge Polishing

• The feed of edging material, by ** strip ** or coil is automatic and synchronously with panel feed.
• Total enclosure covers with dust hood connector.
• Heavy and rigid construction to ensure necessary accuracy and stability.
• To guarantee straight-line feed of the panel, a double row of rubber toothed rollers is off centered onto top pressure beam and bottom feed track with rubber calibrated pads is running on cylindrical guide.
• The top pressure beam is supported with two reinforced columns are equipped with visible linkages for thickness adjustment.
• Extension rollers support for wider panels.
• The electric and pneumatic system is incorporated in the built-in control cabinets.
• Side Pressure Unit: Standard with one row of vertical rollers for straight edges.
• Pre-Milling Unit: Two pre-milling heads running different direction to clean the surface without breaking the edge.
• Gluing Unit: With the use of HOT melt glue applied on straight Panel for edges banding.
• End Cutting Unit: Pneumatic guillotine application for cutting end of band material
• Double End Trimming Unit: Application for fine trimming front & rear edge by saw blade with two independent motors
• Edge Rough Trimming Unit: This top and bottom edge heavy trimming unit is complete by cutter head with two independent motors
• Corner Rounding and Edge Fine Trimming Unit: This top and bottom edge fine trimming unit is complete by cutter head with two independent motors to rounding the corner and edge automatically
• Scrapping Unit: Apply for scrapping top and bottom corners of PVC or ABS,
• Grooving Unit: Apply the groove, notch to the material surface.
• Polishing Unit: Apply the finest finish surfacing process on top and bottom edge.
